CQM1H-CTB41 Omron PLC Parts Four Pulse Inputs High-Speed Counter Board Inner

Omron CQM1H-CTB41 High-speed Counter Board is an Inner Board that handles four pulse inputs

High-speed Counter Pulse Inputs 1 to 4

The High-speed Counter Board counts high-speed pulses from 50 to 500 kHz
entering through ports 1 to 4, and performs tasks according to the number of
pulses counted.

Input Modes

The following three Input Modes are available:
• Differential Phase Mode (1x/2x/4x)
• Up/Down Mode
• Pulse/Direction Mode

Comparison Operation

When the PV (present value) of the high-speed counter matches a specified target value or lies within a specified range, the bit pattern specified in the comparison table is stored in internal output bits and external output bits. A bit pattern
can be set for each comparison result, and the external output bits can be output
through an external output terminal as described below.
External Outputs
Up to four external outputs can be produced when either the target value is
matched or a range comparison condition is satisfied.
