Schneider servo motor SH30551P12F2000 SH055/80005/0/1/00/00/00/11/00 In Stock

SH30551P12F2000 servo motor SH3 055 0,5Nm,key,multi,brake,90°conn.IP54/IP65,9k RPM

Maximum mechanical speed 9000 rpm
[Us] rated supply voltage 115...480 V
Phase Three phase
Continuous stall current 0.73 A
Continuous stall torque 4.43 lbf.in (0.5 N.m) 115...480 V three phase
Peak stall torque 13.28 lbf.in (1.5 N.m) 115...480 V three phase
Nominal output power 100 W 115 V three phase
210 W 230 V three phase
400 W 400 V three phase
440 W 480 V three phase
Nominal torque 4.43 Lbf.In (0.5 N.m) 115 V three phase
4.43 Lbf.In (0.5 N.m) 230 V three phase
4.25 Lbf.In (0.48 N.m) 400 V three phase
4.16 lbf.in (0.47 N.m) 480 V three phase
Nominal speed 9000 rpm 480 V three phase
2000 rpm 115 V three phase
8000 rpm 230 V three phase
8000 rpm 400 V three phase
Maximum current Irms 2.9 A
Shaft end Parallel key
Shaft diameter 0.35 in (9 mm)
Shaft length 0.79 in (20 mm)
Key width 0.12 in (3 mm)
IP degree of protection Shaft bushing without shaft seal ring IP54 EN/IEC 60034-5
Motor IP65 EN/IEC 60034-5
Shaft bushing IP65 EN/IEC 60034-5
Encoder type Absolute multiturn SinCos Hiperface
Speed feedback resolution 128 periods
Holding brake With
Holding torque 7.08 lbf.in (0.8 N.m)
Mounting support International standard flange
Motor flange size 2.17 in (55 mm)
Torque constant 0.68 N.m/A 248 °F (120 °C)
Back emf constant 40 V/krpm 68 °F (20 °C)
Number of motor poles 3
Rotor inertia 0.08 kg.cm²
