Schneider servo motor SH30553P12A2000 SH055/80013/0/1/00/00/00/10/00 In Stock

SH30553P12A2000 servo motor SH3 055 1,05Nm,key,multi,nobrake,90°conn.IP54/ IP65,9k RPM

Maximum mechanical speed 9000 rpm
[Us] rated supply voltage 115...480 V
Phase Three phase
Continuous stall current 1.7 A
Continuous stall torque 9.29 lbf.in (1.05 N.m) 115...480 V three phase
Continuous power 680 W
Peak stall torque 30.98 lbf.in (3.5 N.m) 115...480 V three phase
Nominal output power 240 W 115 V single phase
460 W 230 V single phase
880 W 400 V three phase
970 W 480 V three phase
Nominal torque 10.00 Lbf.In (1.13 N.m) 115 V single phase
9.74 Lbf.In (1.1 N.m) 230 V single phase
7.17 Lbf.In (0.81 N.m) 400 V three phase
7.17 lbf.in (0.81 N.m) 480 V three phase
Nominal speed 4000 rpm 230 V single phase
9000 rpm 480 V three phase
2000 rpm 115 V single phase
8000 rpm 400 V three phase
Maximum current Irms 6.5 A
Shaft end Parallel key
Shaft diameter 0.35 in (9 mm)
Shaft length 0.79 in (20 mm)
Key width 0.12 in (3 mm)
IP degree of protection Shaft bushing without shaft seal ring IP54 EN/IEC 60034-5
Motor IP65 EN/IEC 60034-5
Shaft bushing IP65 EN/IEC 60034-5
Encoder type Absolute multiturn SinCos Hiperface
Speed feedback resolution 128 periods
Holding brake Without
Mounting Support International standard flange
Motor flange size 2.17 in (55 mm)
Electrical Connection Rotatable right angled connector
Torque constant 0.62 N.m/A 248 °F (120 °C)
Back emf constant 41 V/krpm 68 °F (20 °C)
Number of motor poles 3
