Schneider servo motor SH30703P12F2000 SH070/60030/0/1/00/00/00/11/00 In Stock

SH30703P12F2000 servo motor SH3 070 3,1Nm,key,multi,brake,90°conn.IP54/IP65,8k RPM

Maximum mechanical speed 8000 rpm
[Us] rated supply voltage 115...480 V
Phase Three phase
Continuous stall current 4.1 A
Continuous stall torque 27.44 lbf.in (3.1 N.m) 115...480 V three phase
Continuous power 1330 W
Peak stall torque 100.01 lbf.in (11.3 N.m) 115...480 V three phase
Nominal output power 460 W 115 V three phase
880 W 230 V three phase
1450 W 400 V three phase
1550 W 480 V three phase
Nominal torque 26.11 Lbf.In (2.95 N.m) 115 V three phase
24.78 Lbf.In (2.8 N.m) 230 V three phase
20.36 Lbf.In (2.3 N.m) 400 V three phase
18.14 lbf.in (2.05 N.m) 480 V three phase
Nominal speed 1500 rpm 115 V three phase
3000 rpm 230 V three phase
6000 rpm 400 V three phase
7200 rpm 480 V three phase
Maximum current Irms 17 A
Shaft end Parallel key
Shaft diameter 0.55 in (14 mm)
Shaft length 1.18 in (30 mm)
Key width 0.20 in (5 mm)
IP degree of protection Shaft bushing without shaft seal ring IP54 EN/IEC 60034-5
Motor IP65 EN/IEC 60034-5
Shaft bushing IP65 EN/IEC 60034-5
Encoder type Absolute multiturn SinCos Hiperface
Speed feedback resolution 128 periods
Holding brake With
Holding torque 17.70 lbf.in (2 N.m)
Mounting support International standard flange
Motor flange size 2.76 in (70 mm)
Torque constant 0.78 N.m/A 248 °F (120 °C)
Back emf constant 49 V/krpm 68 °F (20 °C)
Number of motor poles 3
