Siemens 6ES7323-1BL00-0AA0
| Place of Origin | Germany |
|---|---|
| Brand Name | Siemens |
| Model Number | 6ES7323-1BL00-0AA0 |
| Minimum Order Quantity | 1 |
| Price | Inquiry |
| Packaging Details | Factory sealed packaging |
| Delivery Time | 1-3 work day |
| Payment Terms | T/T |
| Supply Ability | 99+ |
Product Details
| Digital Inputs | 14 | Power Supply | 24 VDC |
|---|---|---|---|
| Dimensions | Varies By Part, Typically Compact Size | Analog Inputs | 4 |
| Quality | New And Original | Model | 3RT1065-6AP36 |
| Outputs | 10 Digital Outputs | Programming Language | STEP 7 |
| Communication Port | Ethernet | Operating Temperature | -25°C To 55°C |
| Condition | 100% Original | Operatingvoltage | 24V DC |
| Compatibility | Siemens PLC Systems | Part Number | 3RF2340-1AA45 |
| Communicationprotocol | PROFINET, PROFIBUS | ||
| Highlight | Siemens PLC digital module,Siemens 6ES7323-1BL00 module,PLC module with warranty |
||
Product Description
Siemens 6ES7323-1BL00-0AA0 SIMATIC S7-300 Digital I/O Module Description
The 6ES7323-1BL00-0AA0 is a high-performance digital input/output (I/O) module from Siemens’ SIMATIC S7-300 series, engineered to deliver reliable signal acquisition and control in demanding industrial automation environments. Combining 16 digital inputs (DI) and 16 digital outputs (DO) in a compact form factor, this module optimizes installation space while reducing system complexity, making it an ideal choice for process control, machine manufacturing, energy management, and water treatment applications .
Designed for versatility, the module supports 24V DC operation (input voltage range: 13-30V for "1" signal, -30 to +5V for "0" signal) and features optocoupler isolation between channels and the backplane bus, with a 500V DC insulation rating for enhanced protection against electrical interference . The digital inputs are compatible with IEC 61131 Type 1 standards, supporting 2-wire/3-wire proximity switches and switches, with a typical input current of 7mA (signal "1") and input delay of 1.2-4.8ms for stable signal processing . Shielded cables can be extended up to 1000m, while unshielded cables reach 600m, enabling flexible long-distance wiring .
For output functionality, the module employs MOSFET high-side switching with a maximum output current of 0.5A per channel and a total module current limit of 4A (3A at 60°C), suitable for driving solenoid valves, DC contactors, signal lamps, and small relays . Built-in short-circuit protection (response threshold: 1A typical) and inductive shutdown voltage limitation (-48V) ensure operational safety and durability . Output delay is as low as 100µs (0→1) and 500µs (1→0), supporting switching frequencies up to 100Hz (resistive load) for high-speed control tasks .
With a compact footprint (40mm width × 125mm height × 120mm depth) and 260g weight, the module mounts seamlessly on standard S7-300 rails and connects via a 40-pin front connector . It operates reliably in a temperature range of -25°C to +60°C (with occasional condensation permitted) and features IP20 protection for control cabinet installations . Power consumption is typically 6.5W, with 80mA max current drawn from both the 24V DC load voltage (L+) and 5V DC backplane bus .
The module integrates seamlessly with S7-300 CPUs via the backplane bus, supporting automatic address assignment by slot position and optional hot-swapping (CPU-dependent) for easy maintenance . Front-panel LED indicators for each input/output channel enable quick status monitoring and troubleshooting. Compliant with RoHS directives and certified for global industrial standards (CE, UL, cULus), the 6ES7323-1BL00-0AA0 remains a trusted solution for legacy S7-300 systems, with new, used, and repaired units available through authorized suppliers.
This Siemens digital I/O module combines rugged construction, high integration, and reliable performance, serving as a critical interface between field devices and control systems in industrial automation workflows requiring precise signal handling and long-term operational stability.
FAQ & Contact:
Q: Are you a trading company or a manufacturer?
A: We are a trading company.
Q: What is your lead time?
A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.
Q: Does your company provide samples? Is it free or do you charge extra?
A: It depends on the goods you need and the quantity you order.
Q: What are your terms of payment?
A: 100% T/T before shipping. If the quantity is large, we can negotiate.
Our Services:
1, All our products are new and original, and of good quality.
2, Our prices are very competitive.
3, We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.
4, All inquiries will be valued and will reply in 24.
Packing & Delivery:
1)100% brand New and Original Factory Seal!
2)Warranty: 1 year
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3-7 days after payment
5) All the goods will be tested before shipment.
