KEYENCE CA-DEIR10X High-Resolution Infrared 2D Camera Lens

Product Overview

KEYENCE CA-DEIR10X is a premium fixed-focus infrared lens designed specifically for KEYENCE's high-performance machine vision systems, delivering exceptional optical clarity and resolution for near-infrared (NIR) and short-wave infrared (SWIR) imaging applications. As a specialized component engineered to complement KEYENCE's industry-leading vision cameras, the CA-DEIR10X provides consistent, distortion-free imaging even in demanding industrial environments, making it ideal for precision inspection, non-destructive testing, and automated quality control processes.

Backed by KEYENCE's reputation for innovative industrial automation technology, the CA-DEIR10X lens is optimized to work seamlessly with KEYENCE's CV-X, CA, and XG series vision systems, enabling users to unlock the full potential of infrared imaging for applications that cannot be addressed with standard visible-light optics. Whether you are inspecting hidden defects in electronic components, checking for contamination in food processing, or verifying the integrity of packaged goods, the CA-DEIR10X delivers the reliable, high-quality image data your automated system needs to make accurate decisions.

Key Features

• 10x Magnification for High-Precision Imaging: Fixed 10x magnification provides detailed close-up imaging of small components, capturing fine surface features and internal structures that are invisible to the naked eye or lower-magnification lenses, enabling accurate defect detection and measurement for micro-sized parts.
• Optimized for Infrared Wavelengths: Engineered with specialized anti-reflection coatings and infrared-transmissive optical glass, the CA-DEIR10X delivers high light transmission across the 700nm to 1700nm near-infrared spectrum, ensuring high contrast, low-noise image capture for infrared inspection applications.
• Low Distortion Optical Design: Precision-engineered aspherical lens elements minimize geometric and chromatic distortion across the entire imaging field, ensuring accurate measurement and consistent image quality from the center to the edges of the sensor, critical for automated inspection and metrology.
• Compact C-Mount Interface: Standard C-mount compatibility fits all KEYENCE C-mount vision cameras and most third-party industrial infrared cameras, providing flexible integration into existing vision systems and custom inspection setups.
• Robust Industrial Construction: Built to withstand the vibration, temperature fluctuations, and continuous operation common in industrial manufacturing environments, the CA-DEIR10X maintains optical alignment and performance over years of use, reducing maintenance and replacement costs.
• Fixed Focus Design for Stable Performance: The fixed-focus configuration eliminates the risk of accidental focus shift during operation, ensuring consistent imaging performance without the need for frequent recalibration, making it ideal for fixed automated inspection stations.

Technical Specifications

Common Applications

Electronics Manufacturing Inspection

In the electronics industry, the CA-DEIR10X is widely used for inspecting printed circuit boards (PCBs), semiconductor wafers, and microelectronic components. Infrared imaging can detect hidden solder joints, internal delamination, voids in bonding, and thermal defects that are not visible with visible light, enabling manufacturers to catch defects before assembly, reducing end-product failure rates and improving overall yield. The 10x magnification is perfect for capturing detailed images of micro-components such as BGA packages, micro-chips, and fine-pitch connectors.

Food and Agriculture Inspection

Near-infrared imaging with the CA-DEIR10X enables non-destructive detection of foreign materials, moisture content, and internal spoilage in food products. It can distinguish between different material types based on infrared absorption properties, making it effective for detecting plastic, glass, or stone contaminants in packaged food, as well as checking for mold or bruising in fruits and vegetables that is not visible on the surface. The high resolution of the CA-DEIR10X allows for accurate detection of even small contaminants in packaged goods.

Pharmaceutical and Medical Device Inspection

For pharmaceutical manufacturing, the CA-DEIR10X is used to inspect blister packaging for correct pill count, detect seal integrity, and identify contamination in injectable drugs. In medical device manufacturing, it can inspect for defects in transparent plastic components, verify weld integrity in catheters, and check for surface defects on orthopedic implants that are not visible under visible light. The low distortion and high resolution of the lens ensure accurate, consistent inspection results that meet strict regulatory requirements for medical and pharmaceutical products.

Non-Destructive Testing (NDT)

The CA-DEIR10X is ideal for non-destructive testing applications such as crack detection in welds, delamination detection in composite materials, and inspection of coatings for thickness uniformity. Infrared imaging can reveal subsurface defects that do not appear on the material surface, allowing manufacturers to identify issues without damaging the part under test, reducing waste and improving product reliability.

Automotive and Aerospace Component Inspection

In automotive and aerospace manufacturing, the CA-DEIR10X is used to inspect composite materials for fiber misalignment, voids, and delamination, as well as check for defects in rubber seals, plastic components, and welded assemblies. The consistent optical performance of the lens ensures reliable inspection results even in high-volume production environments.

Compatibility

The KEYENCE CA-DEIR10X is designed for seamless integration with the following KEYENCE vision system product lines:

• KEYENCE CV-X Series Machine Vision Systems
• KEYENCE XG-X Series Multi-Camera Vision Systems
• KEYENCE CA Series High-Speed Vision Cameras
• KEYENCE IV Series Image-Based Sensors (with C-mount adapter)

It is also compatible with most third-party industrial C-mount infrared cameras with sensor sizes up to 1/1.8", providing flexibility for custom vision system designs.
