SICK Industrial Sensors DFS60B-S1PC10000 Photoelectric Type for Industrial Automation and Object Detection

  • SICK Industrial Sensors DFS60B-S1PC10000 Photoelectric Type for Industrial Automation and Object Detection
Place of Origin Germany
Brand Name SICK
Model Number DFS60B-S1PC10000
Minimum Order Quantity 1
Price INQUIRY
Packaging Details original
Delivery Time In stock/1-3days
Payment Terms T/T
Supply Ability 99+
Product Details
Order No 1036756 Product Type High-Resolution Programmable Incremental Encoder
Series DFS60B Series Mechanical Interface Servo Flange, Solid Shaft
Weight Approx 200g Supply Voltage 4.5 ~ 32 V DC
Power Consumption ≤ 0.7 W (without Load)
Highlight

SICK Industrial Sensors DFS60B-S1PC10000

,

SICK Industrial Sensors Photoelectric Type
Leave a Message
Product Description

SICK DFS60B-S1PC10000 Incremental Encoder | 10000 PPR High Precision Rotary Encoder

Meta Title: SICK DFS60B-S1PC10000 Incremental Encoder 10000 PPR Solid Shaft Industrial Encoder Meta Description: Original SICK DFS60B-S1PC10000 rotary encoder with 10000 pulses resolution, wide voltage supply, IP65 protection, stable speed & position detection for industrial automation machinery.

Product Overview

The SICK DFS60B-S1PC10000 is a high-performance incremental rotary encoder belonging to classic DFS60B series, widely used in industrial motion control field. Adopts solid servo flange structure, built-in high-precision grating code disc, supports 10000 pulses per revolution high resolution output. It features strong anti-interference, wide temperature resistance and stable operation, perfectly adapts to various harsh factory working conditions, accurately detects rotating speed, angle position and running direction for mechanical equipment.

Main Features

  1. High resolution up to 10000 PPR, achieve ultra-precise motion positioning
  2. Dual signal optional TTL/HTL, complete A/B/Z phase differential signal output
  3. Wide working voltage 4.5V~32VDC, compatible with most industrial control systems
  4. Max rotating speed reach 9000rpm, suitable for high-speed operating equipment
  5. Compact aluminum alloy housing, firm and wear-resistant
  6. Front side IP65 dustproof and waterproof, effectively resist oil, dust and splash water
  7. Long service life, stable signal transmission, low failure rate
  8. Standard 6mm solid shaft, easy installation and matching with servo motor, reducer

Technical Specifications

  • Model: DFS60B-S1PC10000
  • Brand: SICK
  • Type: Incremental Rotary Encoder
  • Pulse Resolution: 10000 PPR
  • Output Signal: A, B, Z phase / differential signal
  • Working Voltage: 4.5 ~ 32 V DC
  • Max Response Frequency: 600kHz
  • Max Rated Speed: 9000 rpm
  • Shaft Size: 6mm solid shaft
  • Protection Level: IP65 (front)
  • Working Temperature: -40℃ ~ +100℃
  • Connection: Fixed cable outgoing type
  • Application Type: Speed detection, position feedback, direction judgment

Wide Applications

  • CNC machine tools and machining centers
  • Servo motor and stepping motor matching
  • Packaging, printing and textile machinery
  • Logistics conveyor and lifting equipment
  • Automation assembly production line
  • Robotics motion control system
  • Metallurgy, chemical industry and heavy industrial equipment

Advantages of Choosing SICK DFS60B-S1PC10000

As original genuine SICK industrial encoder, this model has passed strict industrial grade testing. It delivers consistent and accurate feedback signals in long-term continuous operation, effectively improves equipment operation precision and production efficiency. Standard universal installation size, convenient replacement and after-sales maintenance, is the preferred reliable position speed feedback component for industrial automation upgrading and equipment renovation.
